Compact Module Thermodynamic Steam Trap CMTD

The Forbes Marshall compact module is formed by connecting the universal connector thermodynamic steam trap to a pipeline connector. As the name suggests, the module is compact thereby offering ease of installation and operation. Conventional modules, on the other hand, take a long time for installation due to multiple components and welds and are often difficult to maintain.

Markers:: Digitally Enabled, Digital Services Available
Applications:: Distribution header, expansion loop, risers and downcomers, dead ends

Digitally Enabled
FM Digital Services Available

Want help with choosing the right boiler?

Click Here

Single permanent in-line component for ease of specification and installation
Only 2 welds to install in line
Installable in any angular direction without any change in trap position
Forged carbon steel construction for long life
Time to install - less than 45 mins

Variants

CMTD42M-S
CMTD42M-S, is a compact thermodynamic trap module designed with an in-built upstream isolation valve and bypass valve for steam applications upto 42 bar g@425 Deg C.
Know more
CMTD42M-F
CMTD42M-F, is a compact thermodynamic trap module designed with an in built bypass valve, a trap vent valve and a trap test valve for steam applications upto 42 bar g @425 Deg C
Know more
CMTD62M-S
CMTD62M-S, is a compact thermodynamic trap module designed with an in built upstream isolation valve and bypass valve for steam applications upto 62.5 bar g @482 Deg C
Know more
CMTD62M-F
CMTD62M-F, is a compact thermodynamic trap module designed with an in built bypass valve, a trap vent valve and a trap test valve for steam applications upto 62.5 bar g @482 Deg C.
Know more
CMTD250M
CMTD250M, is a compact thermodynamic trap module designed with an in built isolation valve, bypass valve, a trap vent valve and a trap test valve for very high pressure steam applications upto 220 bar @374 deg C.
